Hole pattern RV 10046

Lochbild rund-versetzt RV 10046

Designation according to DIN: RV 10046 (10.0-14)
Designation: hole pattern Rv 10046
Hole diameter: w = 10 mm
Hole spacing: t = 14.00 mm
Rows of holes: staggered Rv
Free cross-section:46.27 %
